Showing 81–96 of 211 results
GK8
* Made in Germany
* Temp Range -40 to 200 Degrees C
* Safety Factor 4:1
* BS EN818 and DNV
* High Quality Grade 80
* RAL 9005 Painted Black
Superior XL by THIELE TWN1805
* Made in GERMANY
* Marking: XL400 / H4 -10
* Stamped Factory Trace Number
* Approved by BG
* Round steel chain for lifting or lashing use.
* Maximum working temperature: -30 to 380 °C
* Standards PAS 1061 (4:1 Safety Factor)
* 25% Stronger than Grade 80
* Finish: Pained Blue
Superior XL by THIELE TWN0072
* Made in GERMANY
* Marking: XL200 / T3-10
* Stamped Factory Trace Number
* Round steel chain for lifting or lashing use.
* Maximum working temperature: -20 to 200 °C
* Standards EN10204, ASTM973, EN818
* 25% Stronger than Grade 80
* Finish: Painted Grey
Industrial Grade 80 and Spring Loaded, Designed for Lifting and Transportation Lashing Applications
Each Weld-On Ring is clearly Marked showing Lift and Pull (Lashing) Rating.
For Lifting the Safety Factor is 4:1, complying with relevant NZ Standards
For Pulling / Lashing the Safety Factor is 2:1, exceeding LTSA guidelines
* Grade 80
* Safety Factor 4:1
* Marking & Traceability
* Standards CE EN1677-1
* Made in China
* Powder Plastified Yellow RAL1003
* Metric Standard Thread
"Straight Lift Rating" Check Chart for 90 Deg Lift
Top Quality Quality from AUSTRIA
* Individual Identification Traceability
* 360 Degree Rotation
* 180 Degree Load Range
* High Grade 10.9 Crack Tested Bolt
Non Stock - Indent Item
Delivery Approx 2 weeks
Tool-free assembly and disassembly
* 360 Degree Rotation
* High Grade 10.9 Crack Tested Bolt
* Forged Super Alloy Steel
* Quenched & Tempered
* 100% Magnaflux Crack Detection
* Powder Plastified Finish
* Grade 80, EN1677
* Metric Standard Thread
Markings..
SLR, CE, Size, WLL, Batch No.
Approx Dimensions (MM)
6mm Hook 1.12T
Retainer 3.2 x 18.1 / Load Pin 7.5 x 22
7/8mm Hook 2T
Retainer 3.2 x 20 / Load Pin 8.9 x 26.6
10mm Hook 3.15T
Retainer 4.3 x 28 / Load Pin 12.6 x 37.4
13mm Hook 5.3T
Retainer 4.3 x 33.1 / Load Pin 15.9 x 38.7
16mm Hook 8.0T
Retainer 4.4 x 41 / Load Pin 20.8 x 34.8
20mm Hook 12.5T
Retainer 5.3 x 44 / Load Pin 23.8 x 60.4
Approx Dimensions (MM)
7/8mm Hook 2.0T
Retainer 4.2 x 20 / Load Pin 8.9 x 26.6
10mm Hook 3.15T
Retainer 4.3 x 24.5 / Load Pin 12.9 x 32.8
13mm Hook 5.3T
Retainer 5.4 x 30 / Load Pin 15.9 x 41
16mm Hook 8.0T
Retainer 4.4 x 41 / Load Pin 20.8 x 34.8
Approx Dimensions (MM)
20mm Hook 12.5T
Retainer 5.3 x 44 / Load Pin 23.8 x 62.2
10mm Set Dimensions
* Load Pin 12.5mm Dia x 31.0mm
* Retainer Pin 4.5mm Dia x 31.0mm
Suits 335 Safety Hks & 270 Pearlinks
Superior XL by THIELE TWN1904
Suits Thiele G100 TWN1840 Clevis Sling Hooks
New Design with "Locking Pin" to hold chain from slidingout under load
Marking
* Manufacturer Brand
* Identification batch testing number
* Size of the component
* Rating of the component.
* Safety Factor 4:1
For Certificates Click "Download"
CLEARANCE Priced Product..
Refer "THIELE" G100 Clevis Grab Hks
With Cradle to support load chain (No Load Reduction)
For Certificates Click "DOWNLOADS"
