Sizing Ratings
2.3T Ring 6mm 1L / 6mm 2L
5.0T Ring 10mm 1L / 8mm 2L
7.6T Ring 13mm 1L / 10mm 2L
10.0T Ring 16mm 1L / 13mm 2L
14.0T Ring 19mm 1L / 16mm 2L
25.1T Ring 22mm 1L / 19mm 2L
30.8T Ring 26mm 1L / 22mm 2L
40.0T Ring 32mm 1L / 26mm 2L
60.0T Ring 32mm 2 Leg
Features of SLR Grade 100 Components…
* Forged Super Alloy Steel
* Quenched and Tempered
* 25% Stronger than Grade 80
* Individually Proof Tested to 2.5 Times the WLL
* Fatigue tested to 1.5 Times the WLL for 20,000 Cycles
* 100% Magnaflux Crack Detection
* RAL5015 Powder Finish
