Extra Info
1 Fall Units: 0.25T, 0.50T, 1.0T, 1.5T & 2.0T 2 Fall Units: 3.0T & 5.0T
3 Fall Units: 7.5T 4 Fall Units: 10.0T 6 Fall Units: 15T
8 Fall Units: 20.0T 12 Fall Units: 30.0T
Twin Head Block (2 Person Operation) Units: 15.0T, 20.0T & 30.0T
FEATURES
• Lightweight robust construction
• Super strength alloy loadchain
• Fully machined liftwheel
• Minimum headroom
• Minimum effort to raise maximum load
• Cast steel safety latches
• Lower hook complete with thrust race
• Fully enclosed gear train
• Weather protected automatic Weston brake with unique Twin Pawls
• Zinc Plated Alloy Grade 80 Load Chain
• Durable baked enamel paint protection
• Stainless Steel labels
• Spare parts always available
Packaging… These items are to large for Courier Bags
Hoist Packed Weight – Standard 3m Lift
0.50T 11kg, 1.0T 13kg, 1.5T 14kg, 2.0T 23kg, 3.0T 33kg, 5.0T 48kg, 10.0T 70kg
